SunGene
Agricultural IoT
Product Family Selection Sheet
SG-AQM-104: Indoor CO2 and Ambient Air Quality Sensor

LoRaWAN Indoor Multi-Parameter Air Quality Sensor

Configurable indoor LoRaWAN monitor with a 4.2-inch e-paper display and selectable CO₂, PM, TVOC, temperature, humidity and room-context sensors.

Category: Environmental & Agriculture Sensors

Pictured: SG-AQM-104 — Indoor CO2 and Ambient Air Quality Sensor.

Specifications & version options

Parameter optionsTemperature, humidity, CO₂, TVOC, barometric pressure, illuminance, PIR, PM2.5 / PM10, formaldehyde or ozone
Display4.2-inch black-and-white e-paper
Wireless networkLoRaWAN; regional plan confirmed before quotation
Local functionsData storage, status indication and buzzer
PowerUSB Type-C
InstallationFlexible indoor mounting with anti-theft option
Configuration optionsInstalled sensor modules are listed in the quotation

Confirm the sensing configuration before quotation

This indoor monitor is supplied with selected measurement channels. The quotation lists the installed sensors.

  • Documented sensor options include temperature, humidity, CO₂, TVOC, barometric pressure, illuminance, PIR, PM2.5 / PM10, formaldehyde and ozone.
  • The 4.2-inch black-and-white e-paper display, local data storage, status indicator, buzzer and USB Type-C power are available on the selected model.
  • The unit communicates over LoRaWAN. The regional frequency plan, gateway, network server and payload fields must be confirmed for the destination country and platform.
  • The final quotation lists the installed sensor modules. Parameters not listed in the quotation are not implied.
  • Install the selected monitor indoors. Include the room conditions, sensing position and power connection in the equipment request.

Typical applications

  • Track indoor CO₂, temperature and humidity for ventilation review
  • Add PM2.5 / PM10 or TVOC where the project needs those trends
  • Use illuminance or PIR options for room-use context
  • Store readings locally and send selected fields through LoRaWAN
  • Provide local status indication or buzzer alerts when specified

Inquiries: contact@sungeneiot.com · sungeneiot.com

Select the required measurements and connection options from this sheet. Include the quantity, destination and accessories in your equipment request.
